BendPak PL6000DC-ADD-ON Shared Column Add-On Platform & Column Set 6,000 lbs
$9,395.00
BendPak PL6000DC-ADD-ON Shared Column Add-On Platform & Column Set 6,000 lbs is part of our vehicle lift accessories selection from BendPak.
- Lifting capacity: 6000 lb
BendPak PL6000DC-ADD-ON Shared Column Add-On Platform & Column Set 6,000 lbs
BendPak PL6000DC-ADD-ON Shared Column Add-On Platform & Column Set 6,000 lbs is part of our vehicle lift accessories selection from BendPak.
Match the lifting system to the vehicle or load, the service task and the available workspace. Check rated capacity, lift-point compatibility, slab requirements and installation clearances.
Equipment details
- 6,000 lbs. lifting capacity (2,722 kg) accommodates a wide range of vehicles including SUVs, sedans, pickups, vans, sports cars, and light trucks
- Ganged column design allows multiple installations in minimum space, reducing installation costs and maximizing parking density
- Freestanding when ganged two-wide or wider simplifies anchoring requirements and installation logistics
- Galvanized and corrugated anti-slip platform with 82.5-inch usable width accommodates wide modern vehicles
- Full-width channel-locked center panels protect vehicles parked below from debris and fluids
- Adjustable platform height up to 82.5 inches allows customization for various vehicle sizes and ceiling heights
- Fast operation with 50-second lift time and 45-second gravity-driven lowering time reduces energy consumption
- Maintenance-free composite carriage bearings eliminate lubrication requirements and reduce long-term maintenance costs
- Add-On Shared Column Platform & Column Set w/Large Wheel Plate for PL6000DC 2 Post lift
- Space-Saving Ganged Column Design: Supports multiple lift installations in minimal space to maximize parking capacity.
Check the configuration
Use the Additional information tab to review the listed specifications. Confirm the model, included components and site requirements against the manufacturer documentation before ordering. Optional accessories or configurations must be identified separately; an image alone does not establish what is included.
Manufacturer documentation
| Brand |
BendPak |
|---|---|
| MPN / Model |
5176262 |
| Condition |
New |
| Lifting Capacity |
6,000 lbs. (2,722 kg) |
| Overall Height |
126.5" (3,221 mm) |
| Overall Length |
148.25” (3,766 mm) |
| Overall Width |
93.5" (2,385 mm) |
| Usable Platform Width |
82.5" (2,100 mm) |
| Lifting Height |
82.5" (2,100 mm) |
| Lifting / Lowering Time |
50 / 45 sec |
| Electrical Required |
220-420V, 1 or 3 Phase, 50/60Hz |
| Control Power |
24V |
| Lock Release |
Electric Auto Release |
| Power Pack |
2.2kw Hydraulic Power Pump |
| Shipping Dimensions |
150" x 35" x 32" |
| Shipping Weight |
1934 lbs |
| Lifting capacity |
6000 lb |
| Lift type |
Vehicle Lift Accessories |
