BendPak PCL-18B-8 18,000 lb. per Portable Column Lift (Set of 8) – New Gray
$99,495.00
BendPak PCL-18B-8 18,000 lb. per Portable Column Lift (Set of 8) – New Gray is part of our 4 post lifts – heavy-duty selection from BendPak.
- Lifting capacity: 18000 lb
13 in stock
BendPak PCL-18B-8 18,000 lb. per Portable Column Lift (Set of 8) – New Gray
BendPak PCL-18B-8 18,000 lb. per Portable Column Lift (Set of 8) – New Gray is part of our 4 post lifts – heavy-duty selection from BendPak.
Match the lifting system to the vehicle or load, the service task and the available workspace. Check rated capacity, lift-point compatibility, slab requirements and installation clearances.
Equipment details
- 144,000 lb. total system capacity (8-column set) with 18,000 lb. individual column capacity
- Meets or exceeds ANSI/ALI ALCTV-2011 standards ALI certified for safety and quality
- 208-240V, 3-phase main power system with optional voltages available upon request
- SINGLE, PAIR, or TEAM operation modes for ultimate flexibility and control
- Space-saving horseshoe wiring configuration leaves front or back of lift clear of cable obstructions
- Two-speed lowering option (turtle or rabbit speed settings) for safe, controlled descents
- Smart electronics with self-diagnostics and self-calibration for reliable operation and easy troubleshooting
- Ergonomic pallet-jack style steering with adjustable Cush-Ride™ front wheels for effortless mobility
- Low-pressure HVLP direct-drive cylinders eliminate lifting chains and reduce maintenance costs
- Designed and assembled in the USA Santa Paula, California
Check the configuration
Use the Additional information tab to review the listed specifications. Confirm the model, included components and site requirements against the manufacturer documentation before ordering. Optional accessories or configurations must be identified separately; an image alone does not establish what is included.
Manufacturer documentation
| Brand |
BendPak |
|---|---|
| MPN / Model |
5175294-V001 |
| Condition |
New |
| Max Column Capacity |
18,000 lbs. / 8,165 kg (ea) |
| A Overall Height (Raised) |
101” (2,565 mm) |
| B Overall Height (Lowered) |
146.5” (3,721 mm) |
| C Max Lifting Height |
71.5” (1,889 mm) |
| D Overall Depth |
48.75” (1,238 mm) |
| E Overall Width |
45” (1,143 mm)/center> |
| C Chassis Length |
32.25” (819 mm) |
| G Min Lifting Fork Width |
9.5” (241 mm) |
| H Max Lifting Fork Width |
35” (889 mm) |
| I Lifting Fork Length |
11.5” (292 mm) |
| Turning Circle |
40" (1,016 mm) |
| Column Weight |
Each 1,450 lbs. (657 Kg) |
| Lifting Speed |
85 sec |
| Motor |
208 V – 240 V / 50 Hz – 60 Hz / 3 Ph |
| Shipping Weight |
1,450 lbs. / 657 kg (Ea. Column) |
| Lifting capacity |
18,000 lb |
| Lift type |
4 Post Lifts – Heavy-Duty |
| Phase |
Three phase |
| Voltage |
208 V |
