AMGO® Hydraulics BP-12 Symmetric Floor Base-Plate 2 Post Lift 12,000 lbs
$4,950.00
AMGO® Hydraulics BP-12 Symmetric Floor Base-Plate 2 Post Lift 12,000 lbs is part of our 2 post lifts selection from AMGO Hydraulics.
- Lifting capacity: 12000 lb
7 in stock
AMGO® Hydraulics BP-12 Symmetric Floor Base-Plate 2 Post Lift 12,000 lbs
AMGO® Hydraulics BP-12 Symmetric Floor Base-Plate 2 Post Lift 12,000 lbs is part of our 2 post lifts selection from AMGO Hydraulics.
Match the lifting system to the vehicle or load, the service task and the available workspace. Check rated capacity, lift-point compatibility, slab requirements and installation clearances.
Equipment details
- 12,000 lbs lifting capacity handles heavy trucks, SUVs, and commercial vehicles with ease
- Base-plate design with no overhead beam maximizes headroom in low-ceiling garages
- Maximum lifting height of 81 9/16" ~ 82 7/8" with adapters provides ample clearance for undercarriage work
- Single-point safety release and dual locking system for faster operation and enhanced safety
- Adjustable column width (118 1/8" or 123 1/2") adapts to different vehicles and shop layouts
- 3" and 6" Extension Adapters to accommodate different vehicle lift points and heights
- Tool Tray for convenient storage of tools and hardware during service
- Extension Frames for expanded vehicle coverage
- 14-Piece Standard Anchor Bolts for secure floor mounting
- Overall height: 122 1/2" (3110mm) – ideal for garages with limited ceiling clearance
Check the configuration
Use the Additional information tab to review the listed specifications. Confirm the model, included components and site requirements against the manufacturer documentation before ordering. Optional accessories or configurations must be identified separately; an image alone does not establish what is included.
| Brand |
AMGO Hydraulics |
|---|---|
| MPN / Model |
BP-12 |
| Condition |
New |
| Lifting Capacity |
12,000 lbs |
| A Max Lifting Height w/o Adapters |
72 1/2" ~ 73 7/8" |
| A Max Lifting Height w/Adapters |
81 9/16" ~ 82 7/8" |
| A Max Lock Height w/o Adapters |
70 9/16" ~ 71 7/8" |
| A Max Lock Height w/Adapters |
79 9/16" ~ 80 15/16" |
| B Overall Height |
122 1/2" |
| C Overall Width |
145 3/8" or 150 3/4" |
| D Drive-Thru Clearance |
104 7/16" or 109 13/16" |
| E Width Between Columns |
118 1/8" or 123 1/2" |
| F Minimum Pad Height |
4 1/2" |
| Lifting Time |
65 S |
| Motor |
2 HP / 220V |
| Gross Weight |
2,238 lbs |
| Lifting capacity |
12000 lb |
| Lift type |
2 Post Lifts |
| Voltage |
220 V |
