Nationwide NW-9KACD Asymmetric & Symmetric Two Post Car Lift 9,000 lbs
$2,295.00
Nationwide NW-9KACD Asymmetric & Symmetric Two Post Car Lift 9,000 lbs is part of our 2 post lifts selection from Nationwide.
- Lifting capacity: 9000 lb
6 in stock
Nationwide NW-9KACD Asymmetric & Symmetric Two Post Car Lift 9,000 lbs
Nationwide NW-9KACD Asymmetric & Symmetric Two Post Car Lift 9,000 lbs is part of our 2 post lifts selection from Nationwide.
Match the lifting system to the vehicle or load, the service task and the available workspace. Check rated capacity, lift-point compatibility, slab requirements and installation clearances.
Equipment details
- 9,000 lb. capacity handles a wide variety of vehicles from sedans to light-duty trucks
- Dual metric arms with asymmetric and symmetric positioning for flexible vehicle access
- Three-stage front arms extend from 25.5" to 44.25" for precise reach adjustment
- Direct drive cylinder design ensures lift stability and long-term reliability
- Powered by a 3 HP motor running on standard 220V / 1 phase power
- Fast 55-second rise time keeps your shop moving efficiently
- Stackable height adapters included for maximum versatility across vehicle types
- Dual Metric Arms: Features both asymmetric and symmetric 3-stage front arms for flexible vehicle positioning
- Adjustable Screw Pads: Includes stackable adapters (1.5" and 5") for customized lifting height
- Wide Drive-Through Clearance: 96" distance between arms for easy vehicle access
Check the configuration
Use the Additional information tab to review the listed specifications. Confirm the model, included components and site requirements against the manufacturer documentation before ordering. Optional accessories or configurations must be identified separately; an image alone does not establish what is included.
| Brand |
Nationwide |
|---|---|
| MPN / Model |
NW-9KACD |
| Condition |
New |
| Max Lifting Height |
72"- (77.75" w/Adapters) |
| Column Height |
145.4" / 149.3" |
| Total Width (outside base plate) |
139 1/2" |
| Drive-Through Clearance |
96" |
| Floor to Overhead Switch |
136.75" / 140.75" |
| Front Arm Reach (Min/Max) |
25.5" / 44.25" Three stage arm |
| Rear Arm Reach (Min/Max) |
39.5" / 57.5" |
| Drop-in Pad Height |
4" – 10" |
| Inside Column Width |
115.75" |
| Motor / Voltage |
3 HP / 220V / 1 phase |
| Rise |
55 seconds |
| Max Load Per Arm |
2250 lbs / 2500 lbs |
| Lifting capacity |
9,000 lb |
| Lift type |
2 Post Lifts |
| Voltage |
220 V |
