BendPak HD-7500PBX Vehicle & Boat Storage Lift w/Extended Height
$10,095.00
BendPak HD-7500PBX Vehicle & Boat Storage Lift w/Extended Height is part of our parking lifts selection from BendPak.
14 in stock
BendPak HD-7500PBX Vehicle & Boat Storage Lift w/Extended Height
BendPak HD-7500PBX Vehicle & Boat Storage Lift w/Extended Height is part of our parking lifts selection from BendPak.
Match the lifting system to the vehicle or load, the service task and the available workspace. Check rated capacity, lift-point compatibility, slab requirements and installation clearances.
Equipment details
- 7,500 lb lifting capacity handles boats, cars, trucks, and specialty vehicles with ease
- Extended 144.5" maximum rise accommodates taller boats and lifted vehicles
- 30 locking positions every 4 inches for flexible, variable-height parking and storage
- Electric/hydraulic power system with 208-230 VAC motor for smooth, reliable operation
- Push-button pneumatic safety release lowers all four locks simultaneously for fast, convenient lowering
- Heavy-duty 3/8" stainless steel aircraft cables provide exceptional strength and corrosion resistance
- Wide and narrow installation options with adjustable runway spacing accommodate different wheelbases
- Integrated rail-kit on runways accepts optional accessories for enhanced versatility
- Low 5" minimum runway height allows easy drive-on access for low-clearance vehicles and trailers
- Durable powder coat finish resists corrosion and maintains a professional appearance for years
Check the configuration
Use the Additional information tab to review the listed specifications. Confirm the model, included components and site requirements against the manufacturer documentation before ordering. Optional accessories or configurations must be identified separately; an image alone does not establish what is included.
Manufacturer documentation
| Brand |
BendPak |
|---|---|
| MPN / Model |
5175320 |
| Condition |
New |
| Lifting Capacity: (*) |
7,500 lbs. / 3,175 kg |
| Max capacity / Rear Axle: |
3,750 lbs. / 1,701 kg |
| A Min. Runway Height |
5" (125 mm) |
| D Overall Width |
132.5" (3,358 mm) (with fasteners 133.75" / 3,398 mm) |
| H Width Between Columns |
122" / 3,103 mm |
| I Drive-Thru Clearance |
108.5" / 2,756 mm |
| J Runway Width |
19" / 483 mm |
| N Outside Edge of Runways |
87.5" narrow or 107.5" wide (2,223 or 2,731 mm) |
| Drive-Thru Clearance |
108.5 " / 2,756 mm |
| Lock Spacing |
Every 4" (102 mm) |
| Motor |
208-230 VAC, 60 Hz, 1 Ph |
| Air Supply |
3 to 25 cfm @ 50 to 150 psi |
| Lift type |
Parking Lifts |
| Phase |
Single phase |
| Voltage |
208-230 V |
