Auto Lift Car-Park-9 9,000 lb. Storage/Parking & Service Lift
$4,950.00
Auto Lift Car-Park-9 9,000 lb. Storage/Parking & Service Lift is part of our parking lifts selection from Auto Lift.
- Lifting capacity: 9000 lb
Auto Lift Car-Park-9 9,000 lb. Storage/Parking & Service Lift
Auto Lift Car-Park-9 9,000 lb. Storage/Parking & Service Lift is part of our parking lifts selection from Auto Lift.
Match the lifting system to the vehicle or load, the service task and the available workspace. Check rated capacity, lift-point compatibility, slab requirements and installation clearances.
Equipment details
- Commercial-Grade Construction: Built to withstand the demands of professional shops with heavy-duty components and a durable powder coat finish
- Dual-Purpose Design: Functions seamlessly as both a vehicle storage lift and a full-service lift for maintenance and repairs
- Non-Skid Diamond Plate Runways: Provides secure vehicle positioning and enhanced safety during loading and service operations
- Single-Point Manual Lock Release: Simplifies operation with easy, intuitive locking and unlocking from one convenient location
- Adjustable Lock Ladder Leveling: Features 11 locking positions for precise height adjustment and versatile working configurations
- 9,000 lbs. capacity
- Commercial grade Lift
- Non-skid Diamond Plate Runways
- Adjustable Lock Ladder leveling
- Single Point, Manual Lock release
Check the configuration
Use the Additional information tab to review the listed specifications. Confirm the model, included components and site requirements against the manufacturer documentation before ordering. Optional accessories or configurations must be identified separately; an image alone does not establish what is included.
| Brand |
Auto Lift |
|---|---|
| MPN / Model |
AutoLift-Car-Park-9-V001 |
| Condition |
New |
| Capacity |
9,000 lbs. |
| Overall Length w/Ramp |
239" |
| Overall Length No Ramp |
197" |
| Overall Width |
123" |
| Overall Width w/Power Unit |
134.5" |
| Column Height |
97" |
| Lifting Height |
85" |
| Approach Ramp Length |
37" |
| Runway Tread Width |
20" |
| Runway Length |
188.5" |
| Runway Height |
4.80" |
| Clearance between Columns |
111.5” |
| Clearance between Runways |
39.5" |
| Outside Runway to Outside Runway |
79” |
| Clearance Under Runways |
81" |
| Drive Thru Width |
99" |
| Locking Position |
11 |
| Lifting Speed |
100 sec |
| Power |
110V-20 Amp / 1PH |
| Ship Weight |
2,354 lbs. |
| Lifting capacity |
9,000 lb |
| Lift type |
Parking Lifts |
